Techniical Data:
| Model Number | SMV100P1-30 | SMV100P2-30 |
| Head configuration | 110v/60Hz/1 | 220v/50Hz/1 |
| Maximum Current | 1.2A | 0.6A |
| Maximum Power | 100W | 100W |
| Maximum flow | 30L/min | 30L/min |
| Maximum vacuum degree | -85kpa | -85kpa |
| Speedat rated load | 1650rpm | 1400rpm |
| Noise | ＜53dB(A) | ＜53dB(A) |
| Maximum pressure restart | 0 PSI | 0 PSI |
| Motor type (capacitance ) | P.S.C(6.5uF) | P.SC(3uF) |
| Motor insulation class | B | B |
| Thermal switch (open temperture) | Thermally protected(145℃） | Thermally protected(145℃） |
| Line lead wire color,gauge | White(hot),black(neutral),20AWG | Brown(hot),blue(neutral),20AWG |
| Capacitor lead wire color ,gauge | Blue ,blue,20AWG | Black ,black,20AWG |
| Operating ambient air temperature | 50° to 104°F(10°to 40℃） | 50° to 104°F(10°to 40℃） |
| Safety certification | ETL | ETL |
| Net weight | 2.4kg | 2.4kg |
Other voltages and configurations avaiable upon request
